| POS |
Part Number |
Description |
Qty. Needed |
Price |
Model/Option Info |
|
1
|
|
interior mirror |
1 |
- |
CARRERA |
|
|
|
|
|
- |
TURBO |
|
|
477857511A01C
|
black |
|
$199.99 |
|
|
(1)
|
|
interior mirror(FOR YEAR 1989 & up) |
1 |
- |
SPEEDSTER |
|
|
9117311010001C
|
black |
|
- |
|
|
1A
|
99921903202
|
countersunk-head screw micro-self-locking m 5 x 12(FOR YEAR 1989 & up) |
2 |
$5.79 |
SPEEDSTER |
|
2
|
91173190102
|
installation set door mirror without mirror glass for subsequent installation(LEFTHAND DRIVE, PASSENGER SIDE) |
1 |
- |
|
|
3
|
91173192701
|
repair kit driver's door(LEFTHAND DRIVE, LEFT) |
1 |
- |
|
|
(3)
|
91173192801
|
repair kit passenger's door(LEFTHAND DRIVE, PASSENGER SIDE) |
1 |
- |
|
|
4
|
91173104303
|
mirror housing(DRIVER SIDE) |
1 |
$57.50 |
|
|
(4)
|
91173104403
|
mirror housing(PASSENGER SIDE) |
1 |
$79.93 |
|
|
4A
|
94473114300
|
seal |
2 |
- |
|
|
5
|
91173124102
|
mirror base(LEFTHAND DRIVE, LEFT) |
1 |
$180.42 |
|
|
(5)
|
91173128802
|
mirror base(LEFTHAND DRIVE, PASSENGER SIDE) |
1 |
$180.42 |
|
|
5(Apr)
|
|
mirror housing(DRIVER SIDE) |
1 |
- |
|
|
|
94473102101G3M
|
with mirror base grey prime coated |
|
$72.01 |
|
|
6
|
91173126300
|
mounting piece |
2 |
$13.12 |
|
|
7
|
99914300302
|
hexagon-head bolt m 5 x 10 |
3 |
$1.15 |
|
|
8
|
94473102701
|
electric installation set |
2 |
- |
|
|
9
|
94473103502
|
mirror glass plane(DRIVER SIDE) |
1 |
$29.15 |
|
|
(9)
|
94473103506
|
mirror glass convex(PASSENGER SIDE) |
1 |
$226.42 |
|
|
11
|
91173124700
|
desk pad(DRIVER SIDE) |
1 |
$5.78 |
|
|
(11)
|
91173124800
|
desk pad(PASSENGER SIDE) |
1 |
$5.73 |
|
|
12
|
91153119700
|
reinforcement(DRIVER SIDE) |
1 |
$20.66 |
|
|
(12)
|
91153119800
|
reinforcement(PASSENGER SIDE) |
1 |
$20.66 |
|
|
13
|
99919012302
|
blind rivet 3,2 x 7,37 |
2 |
$1.47 |
|
|
14
|
9992180210C
|
pan-head screw am 5 x 35 |
1 |
$5.21 |
|
|
15
|
99970313740
|
cap |
1 |
$2.05 |
|
|
16
|
91173125703
|
guide tube |
1 |
$36.11 |
|
|
17
|
91173134502
|
centring washer lower |
1 |
$6.25 |
|
|
18
|
91173102901
|
compression spring |
1 |
$5.31 |
|
|
19
|
91173134700
|
centring washer upper |
1 |
$6.25 |
|
|
20
|
92861324100
|
switch |
1 |
$117.38 |
|
|
21
|
91173134303
|
gasket |
1 |
$9.00 |
|
|
22
|
91161342300
|
assembly frame |
1 |
$9.21 |
|
|
23
|
|
rosette |
1 |
- |
|
|
|
9116134250001C
|
black |
|
$7.15 |
|
|
24
|
9116130820001C
|
knob |
1 |
$12.28 |
|
|
|
9116130820001C
|
black |
|
$12.28 |
|
|
25
|
|
support |
1 |
- |
|
|
|
9116136150101C
|
black |
|
$10.71 |
|
|
26
|
92861324000
|
rocker switch |
1 |
$70.46 |
M261YEARDESCRIPTION1978-1989DOOR MIRROR - FLAT - PASSENGER'S SIDE, ELECTRICALLY ADJUSTABLE AND HEATABLEM528YEARDESCRIPTION1978-1989DOOR MIRROR FOR PASSENGER'S SIDE - CONVEX - ELECTRICALLY HEATABLE AND ADJUSTABLE |
|
|
9286132400001C
|
satin black |
|
$115.48 |
|
|
26A
|
|
adapter plug |
1 |
- |
|
|
|
9286123250001C
|
satin black |
|
$57.51 |
|
|
27
|
803971980
|
pin connector socket 7-pole |
1 |
$5.02 |
|
|
28
|
N0175641
|
round connector 1,6 - 1 |
X |
$1.10 |
|
|
29
|
803971979
|
plug socket 7-pole |
1 |
$5.02 |
|
|
30
|
171971999A
|
terminal sleeve housing 2-pole |
1 |
$1.97 |
|
|
31
|
477957861
|
rubber sleeve |
1 |
$7.68 |
|
|
32
|
99970213640
|
rubber sleeve 8 x 31 x 7 |
1 |
$3.23 |
|
|
(33)
|
91161216504
|
wiring harness driver's door |
1 |
- |
|
|
33
|
91161216505
|
wiring harness driver's door with alarm system(LEFTHAND DRIVE) |
1 |
- |
|
|
(33)
|
91161216604
|
wiring harness passenger's door |
1 |
$68.38 |
|
|
34
|
92861254200
|
clutch housing 5-pole |
1 |
- |
|
|
35
|
94461254800
|
contact bush |
4 |
$2.90 |
|
