The KW Suspension Variant 3 Coilover System is state-of-the-art technology derived from motorsports competition for a more precise performance on the road. The separate and independently adjustable rebound and compression Dampening allows for individual suspension setups with different uses and preferences. The unique patented system with its two-stage valves allows a rebound Dampening adjustment (comfort) and a compression adjustment (driving dynamics) in the low-speed range, while the high-speed range which controls the driving safety, is fixed. _x000B_ _x000B_ _x000B_Rebound Adjustment _x000B_ _x000B_Being vehicle-specifically possible, the rebound Dampening is adjusted by a spindle at the end of the piston rod. Mainly, the traction phase (rebound) controls car body vibrations and also influences handling and comfort in the low-speed Dampening range. _x000B_ _x000B_By using the traction phase adjustment, the vehicle can be adapted to the requirements of the driver. Moreover the driving behavior can be regulated from comfortably rolling to sporty and tense with improved road holding characteristics. _x000B_ _x000B_ _x000B_Compression Adjustment _x000B_ _x000B_The compression phase adjustment is carried out at the lower end of the shock absorber via KWs patented multi-purpose valve. The large number of pre-set parameters of this valve allows for a wide range of adjustment for individual use. The unique low-speed compression adjustment significantly distinguishes this technology from any other. _x000B_ _x000B_In the compression range, the driving behavior of the vehicle is drastically influenced. An increase of the Dampening power supports the vehicle already during compression and therefore avoids rolling and pitching, significantly improving the directional stability. _x000B_ _x000B_ _x000B_KW Hydraulic Lift System _x000B_ _x000B_The KW Suspension Hydraulic Lift System provides additional road clearance for lowered vehicles. When expanded, a range of up to 45mm of lift is produced, thereby helping lowered cars avoid road clearance difficulties such as speed bumps or road construction. _x000B_ _x000B_The HLS 2 System is attached to the front axle and allows lifting of the front of the vehicle. The hydraulic cylinder unit is located on the coilover body between spring perch and spring. One advantage of a hydraulic system is that there is no compression (motion) of the extended cylinder unit (resulting in no unwanted additional suspension movement) while driving. _x000B_ _x000B_This KW Hydraulic Lift System is a vehicle-specific solution as a complete kit with KW Variant 3 coilovers. KW HLS kits may utilize existing springs, or provide springs (depending on application) and include all associated hardware, hydraulic cylinder and the control unit. _x000B_ _x000B_Allows cars with low ground clearance to clear obstacles more easily
