| POS |
Part Number |
Description |
Qty. Needed |
Price |
Model/Option Info |
|
1
|
94450107500
|
boot floor plate |
1 |
$599.48 |
|
|
2
|
477803581
|
lid tank gauge |
1 |
$6.00 |
|
|
3
|
411803595
|
lid |
1 |
$55.21 |
|
|
4
|
477813115B
|
transmission carrier(UP TO YEAR 77) |
1 |
- |
924 |
|
4
|
477813115B
|
transmission carrier(FOR YEAR 1978 & up) |
1 |
- |
|
|
(4)
|
477813115C
|
transmission carrier(FOR YEAR 1979 & up) |
1 |
- |
|
|
5
|
477813131
|
spare-wheel well(FRONT) |
1 |
$253.00 |
|
|
5A
|
477813187
|
impact absorber plate((CDN) (USA)) |
1 |
- |
|
|
5B
|
N01023930
|
hexagon-head bolt m 8 x 18((CDN) (USA)) |
3 |
$3.26 |
|
|
5C
|
90002701502
|
lock ring((CDN) (USA)) |
3 |
$1.10 |
|
|
5C
|
90002701503
|
lock ring((CDN) (USA)) |
3 |
$1.89 |
|
|
6
|
99970319540
|
drain bush |
3 |
$1.12 |
|
|
7
|
111701309
|
rubber sleeve |
1 |
- |
|
|
8
|
477813145
|
corner panel heel plate f >>92482 01225 f >>92483 30098(DRIVER SIDE) |
1 |
- |
924 |
|
8
|
477813145B
|
corner panel f 92482 01226>> f 92483 30099>>(DRIVER SIDE) |
1 |
- |
|
|
8
|
477813145B
|
corner panel(DRIVER SIDE) |
1 |
- |
|
|
(8)
|
477813146B
|
corner plate heel plate f >>92482 01225 f >>92483 30098(PASSENGER SIDE) |
1 |
$240.97 |
924 |
|
(8)
|
477813146B
|
corner panel f 92482 01226>> f 92483 30099>>(PASSENGER SIDE) |
1 |
$240.97 |
|
|
(8)
|
477813146B
|
corner panel(PASSENGER SIDE) |
1 |
$240.97 |
|
|
9
|
94450303701
|
end plate |
1 |
- |
|
|
-
|
94450234501
|
reinforcement(DRIVER SIDE) |
1 |
$70.75 |
924 |
|
-
|
94450234601
|
reinforcement(PASSENGER SIDE) |
1 |
$95.25 |
924 |
|
10
|
94450390101
|
end plate lower |
1 |
$253.00 |
|
|
-
|
477813169
|
fastening angle scissors type jack(DRIVER SIDE) |
1 |
$30.16 |
|
|
-
|
477813170
|
fastening angle scissors type jack(PASSENGER SIDE) |
1 |
$43.08 |
|
|
-
|
477813165
|
support |
1 |
$36.63 |
|
|
10A
|
477813393A
|
support muffler |
1 |
$3.52 |
|
|
11
|
477813309
|
corner panel(DRIVER SIDE) |
1 |
$45.24 |
|
|
(11)
|
94450221000
|
corner panel(PASSENGER SIDE) |
1 |
$196.99 |
|
|
11A
|
477813159
|
support emergency wheel |
1 |
- |
|
|
(12)
|
94450203502
|
lock carrier see group 8/01/15 pos.27 f >>92472 05780 f >>92473 00212 |
1 |
$722.11 |
|
|
12
|
94450203502
|
lock carrier with reinforcement f 92472 05781>> f 92473 00213>> |
1 |
$722.11 |
|
|
-
|
95151244700
|
reinforcement plate lock carrier |
2 |
$19.55 |
|
|
13
|
477813529
|
towing lug |
1 |
$12.36 |
|
|
14
|
92870105003
|
support((J) (USA)) |
1 |
$39.50 |
|
|
|
|
number plate((CH)) |
|
- |
|
|
15
|
803011243
|
rubber washer |
2 |
$1.44 |
|
|
16
|
N0122265
|
spring washer a 6 |
2 |
$1.00 |
|
|
(16)
|
90015102703
|
washer a 5,3 |
2 |
$1.50 |
|
|
17
|
N0141405
|
oval-head screw m 6 x 15 |
2 |
$2.00 |
|
|
18
|
N02214812
|
hexagon nut m 6 |
2 |
$1.74 |
|
|
18
|
9000760100B
|
hexagon nut m 6 |
2 |
$1.06 |
|
|
18
|
90008402601
|
lock nut((J) (USA)) |
2 |
$1.67 |
|
|
|
|
m 5((CH)) |
|
- |
|
|
(19)
|
94450391201
|
roof |
1 |
$3,707.05 |
M650 |
|
19
|
94450391202
|
roof |
1 |
$2,323.98 |
|
|
20
|
477817171
|
cross member |
1 |
$192.49 |
|
|
21
|
477813285
|
transverse strut seat well f 92482 01226>> f 92483 30099>> |
1 |
$65.03 |
|
|
22
|
90007418102
|
screw m 10 x 95 |
4 |
$2.62 |
|
|
23
|
90002500804
|
washer 10,5 |
4 |
$1.00 |
|
|
25
|
90014313400
|
tapping screw((J) (USA)) |
4 |
- |
|
|
|
|
bz 4,2 x 9,5((CH)) |
|
- |
|
|
26
|
N0115228
|
washer((J) (USA)) |
4 |
- |
|
|
|
|
4,3((CH)) |
|
- |
|
|
27
|
99959149840
|
special nut((J) (USA)) |
4 |
$5.50 |
|
|
|
|
((CH)) |
|
- |
|
