| POS |
Part Number |
Description |
Qty. Needed |
Price |
Model/Option Info |
|
1
|
95151292901
|
rear lid |
1 |
$948.74 |
|
|
2
|
477853313A
|
trim frame |
1 |
$258.67 |
|
|
3
|
95151210100
|
rear spoiler |
1 |
$575.00 |
|
|
|
9515121010003C
|
rally black |
|
$1,379.39 |
|
|
4
|
|
rear spoiler |
1 |
- |
|
|
|
9445121030003C
|
rally black |
|
$718.39 |
|
|
5
|
95151240500
|
rear spoiler(DRIVER SIDE) |
1 |
- |
|
|
|
9515124050003C
|
rally black |
|
- |
|
|
(5)
|
95151240600
|
rear spoiler(PASSENGER SIDE) |
1 |
$403.89 |
|
|
|
9515124060003C
|
rally black |
|
- |
|
|
6
|
N033184A
|
countersunk-head screw m 5 x 22 |
2 |
$4.84 |
|
|
7
|
803955637
|
rubber washer |
4 |
$1.76 |
|
|
8
|
90015102707
|
washer b 5,3 x 15 |
2 |
$1.24 |
|
|
9
|
90003403307
|
nut m 5 |
2 |
- |
|
|
10
|
90026905407
|
countersunk-head screw m 5 x 25 |
2 |
$9.92 |
|
|
11
|
90038000102
|
nut m 5 |
2 |
$8.45 |
|
|
12
|
N10215801
|
pan-head screw m 5 x 8 |
4 |
$3.12 |
|
|
13
|
90002505307
|
washer a 5,3 x 10 |
4 |
$1.69 |
|
|
14
|
95151273301
|
compensating plate |
X |
$8.22 |
|
|
15
|
N0212551
|
slotted nut m 4 |
14 |
$4.11 |
|
|
16
|
90026901702
|
countersunk-head screw m 5 x 12 |
2 |
$1.24 |
|
|
17
|
99970730140
|
o-ring |
1 |
- |
|
|
18
|
90038000102
|
lock nut m 5 |
2 |
$8.45 |
|
|
19
|
95151246502
|
additional gasket |
1 |
- |
|
|
20
|
90025002407
|
screw dm 4 x 16 |
2 |
- |
|
|
21
|
95151260300
|
gasket |
1 |
- |
|
|
22
|
9515126050201C
|
gasket(DRIVER SIDE) |
1 |
$113.38 |
|
|
|
9515126050201C
|
black |
|
$113.38 |
|
|
(22)
|
9515126060201C
|
gasket(PASSENGER SIDE) |
1 |
$113.38 |
|
|
|
9515126060201C
|
black |
|
$113.38 |
|
|
23
|
94451204300
|
seal for rear lid |
1 |
$89.65 |
|
|
24
|
94451203303
|
housing(DRIVER SIDE) |
1 |
$84.45 |
|
|
(24)
|
94451203403
|
housing(PASSENGER SIDE) |
1 |
$102.22 |
|
|
25
|
477827035
|
rubber mounting |
2 |
$35.26 |
|
|
26
|
9992190110H
|
countersunk-head screw m 6 x 16 |
4 |
- |
|
|
27
|
94453854700
|
lock pin |
2 |
$10.65 |
|
|
28
|
N0110088
|
hexagon nut m 8 |
2 |
$1.00 |
|
|
29
|
90002701502
|
lock ring b 8 |
2 |
$1.10 |
|
|
29
|
90002701503
|
lock ring b 8 |
2 |
$1.89 |
|
|
30
|
94451236501
|
gasket(DRIVER SIDE) |
1 |
$105.05 |
|
|
(30)
|
94451236601
|
gasket(PASSENGER SIDE) |
1 |
$110.50 |
|
|
31
|
95151244700
|
reinforcement plate |
2 |
$19.55 |
|
|
32
|
94453895500
|
rear lid lock(DRIVER SIDE) |
1 |
$46.00 |
|
|
(32)
|
94453895600
|
rear lid lock(PASSENGER SIDE) |
1 |
$46.00 |
|
|
33
|
477827541
|
water drip pan |
2 |
$7.60 |
|
|
34
|
N0120064
|
lock ring b 6 |
4 |
$1.00 |
|
|
35
|
N02214812
|
hexagon nut m 6 |
4 |
$1.74 |
|
|
35
|
9000760100B
|
hexagon nut m 6 |
4 |
$1.06 |
|
|
36
|
111971911A
|
rubber sleeve |
2 |
$7.25 |
|
|
37
|
99918112240
|
hose 400 mm |
2 |
- |
|
|
38
|
94451234900
|
gas-pressure spring(DRIVER SIDE) |
1 |
$17.01 |
|
|
(38)
|
94451234800
|
gas-pressure spring(PASSENGER SIDE) |
1 |
$17.01 |
|
|
39
|
477827305B
|
hinge half |
2 |
$17.83 |
|
|
40
|
94451231100
|
hinge pin |
2 |
$4.33 |
|
|
41
|
477827441
|
bush |
2 |
$4.81 |
|
|
42
|
94451241300
|
gasket |
2 |
$6.90 |
|
|
43
|
92851241703
|
plate |
2 |
- |
|
|
44
|
99921804507
|
pan-head screw m 8 x 16 micro-self-locking |
4 |
- |
|
|
45
|
477845333
|
screw plug |
1 |
$67.11 |
|
|
46
|
477955439
|
grommet |
2 |
$14.84 |
|
|
47
|
477845331
|
washer |
1 |
$9.36 |
|
|
48
|
N01111814
|
hexagon nut m 8 |
1 |
- |
|
|
49
|
477827529A
|
sealing ring |
1 |
$6.00 |
|
|
50
|
94453891102
|
lock cylinder w/o stipulated lock number with 2 secondary keys |
1 |
$195.55 |
|
|
50
|
94453807301
|
lock cylinder with stipulated lock number state lock number |
1 |
$298.23 |
|
|
51
|
N0141395
|
oval-head screw m 6 x 12 |
2 |
$1.00 |
|
|
52
|
90002700403
|
lock ring a 6 |
2 |
$1.00 |
|
|
53
|
94462403000
|
microswitch |
1 |
$94.19 |
|
|
54
|
99959191000
|
clamp |
1 |
$2.86 |
|
|
55
|
94462402402
|
electric motor see technical information gr.5,nr.1/93 |
1 |
$166.75 |
|
|
56
|
99908404502
|
lock nut |
1 |
$1.00 |
|
|
57
|
94462481400
|
lever |
1 |
$120.12 |
|
|
58
|
99353156300
|
linkage clip |
1 |
$1.45 |
|
|
59
|
94451209703
|
bowden cable |
1 |
$66.41 |
|
|
60
|
N0124331
|
lock washer |
1 |
- |
|
|
61
|
94451209500
|
lever |
1 |
$148.37 |
|
|
62
|
N0115247
|
washer b 6 |
2 |
$1.10 |
|
|
62
|
N01152427
|
washer b 6 |
2 |
$1.00 |
|
|
63
|
N02214812
|
hexagon nut m 6 |
2 |
$1.74 |
|
|
63
|
9000760100B
|
hexagon nut m 6 |
2 |
$1.06 |
|
|
64
|
94451220100
|
stud |
2 |
$5.98 |
|
|
65
|
99916802500
|
ball socket |
1 |
$10.45 |
|
|
66
|
94451209100
|
pull rod(DRIVER SIDE) |
1 |
- |
|
|
67
|
94451209201
|
pull rod(PASSENGER SIDE) |
1 |
- |
|
|
68
|
99916605401
|
sl-lock |
1 |
$1.39 |
|
