| POS |
Part Number |
Description |
Qty. Needed |
Price |
Model/Option Info |
|
1
|
99761109000
|
ground strap(LEFTHAND DRIVE) |
1 |
$26.50 |
I098 |
|
-
|
90037701001
|
hexagon nut m 6 |
1 |
$1.10 |
|
|
2
|
99961106020
|
battery 60 ah |
1 |
- |
|
|
2
|
99961107020
|
battery 70 ah |
1 |
$186.79 |
|
|
2
|
99961108020
|
battery 80 ah |
1 |
- |
|
|
(2)
|
99761102001
|
battery 18 ah(FROM YEAR 10 UP) |
1 |
$3,997.63 |
I191 |
|
(2)
|
997611020X
|
battery 18 ah(FROM YEAR 10 UP) |
1 |
- |
I191 |
|
3
|
893915507
|
angled pipe |
1 |
$10.92 |
|
|
4
|
99761299300
|
repair kit wiring harness battery power distributor(LEFTHAND DRIVE) |
1 |
- |
I098 |
|
5
|
90038000501
|
hexagon nut vm 8 |
2 |
$1.10 |
|
|
6
|
90037801701
|
hexagon-head bolt m 8 x 20 |
1 |
$3.84 |
|
|
7
|
99661120901
|
rail battery |
1 |
$3.32 |
|
|
8
|
99750415101
|
carrier plate for battery |
1 |
$335.96 |
|
|
-
|
99650462201
|
gasket carrier plate for battery |
1 |
- |
|
|
9
|
99908463001
|
hexagon nut vm 8 sb |
4 |
$1.55 |
|
|
10
|
99761091200
|
repair kit replacement fuse element comprising: |
1 |
$417.88 |
|
|
-
|
|
fuse element 50 ampere |
1 |
- |
|
|
-
|
|
fuse element 70 ampere |
1 |
- |
|
|
-
|
|
fuse element 80 ampere |
1 |
- |
|
|
-
|
|
hexagon nut m 5 |
4 |
- |
|
|
-
|
|
square washer |
4 |
- |
|
|
-
|
|
cover blue |
1 |
- |
|
|
-
|
|
seal label red |
1 |
- |
|
|
(10)
|
99761091300
|
repair kit replacement fuse element comprising: |
1 |
$417.88 |
|
|
-
|
|
fuse element 150 ampere |
1 |
- |
|
|
-
|
|
hexagon nut m 8 |
2 |
- |
|
|
-
|
|
square washer |
2 |
- |
|
|
-
|
|
cover blue |
1 |
- |
|
|
-
|
|
seal label red |
1 |
- |
|
|
11
|
99761091100
|
repair kit replacement power distributor comprising: |
1 |
$755.62 |
|
|
-
|
|
power distributor without fuse element |
1 |
- |
|
|
-
|
|
hexagon nut m 5 |
8 |
- |
|
|
-
|
|
hexagon nut m 8 |
3 |
- |
|
|
-
|
|
seal label red when required order also: pos. 12 |
1 |
- |
|
|
12
|
90008412302
|
hexagon nut m 8 |
1 |
$3.84 |
|
|
13
|
99761209201
|
cable power distributor starter(LEFTHAND DRIVE) |
1 |
$152.19 |
I098 |
|
14
|
99908462901
|
hexagon nut m 6 |
1 |
$1.10 |
|
|
15
|
90007549701
|
combination screw m 5 x 10 |
1 |
$3.84 |
|
|
16
|
99950770201
|
speed nut m 5 |
1 |
$3.84 |
|
|
17
|
99760703192
|
wiring harness starter generator |
1 |
$243.24 |
|
|
19
|
99660410702
|
starter |
1 |
$260.00 |
|
|
19
|
996604107BX
|
starter |
1 |
$1,087.48 |
|
|
20
|
90038509701
|
torx screw bm 10 x 35 |
2 |
- |
|
|
21
|
99660411800
|
protection cap |
1 |
$9.80 |
|
|
22
|
99660703401
|
ground strap engine body |
1 |
$59.60 |
|
|
23
|
99760301206
|
generator(UP TO YEAR 08) |
1 |
$419.97 |
|
|
23
|
99760302204
|
generator(FROM YEAR 10 UP) |
1 |
$481.52 |
|
|
23
|
997603022EX
|
generator(FROM YEAR 10 UP) |
1 |
$570.00 |
|
|
24
|
99660315156
|
pulley |
1 |
$93.61 |
|
|
25
|
N0120161
|
lock ring b 16 |
1 |
$1.27 |
|
|
26
|
90003401301
|
hexagon nut m 16 x 1,5 |
1 |
$8.18 |
|
|
-
|
99660311300
|
protection cap mounting parts generator |
1 |
$13.15 |
|
|
-
|
90038500401
|
torx screw bm 10 x 60 |
1 |
$3.26 |
|
|
-
|
90038512401
|
torx screw bm 10 x 110 |
1 |
$18.15 |
|
|
27
|
90037700301
|
hexagon nut m 8 |
2 |
- |
|
|
28
|
90037701002
|
hexagon nut m 6 |
1 |
$1.41 |
|
|
|
|
battery main switch |
|
- |
I003 |
|
-
|
99761102770
|
assembly kit battery main switch comprising: |
1 |
$1,265.23 |
I003 |
|
-
|
99761122770
|
battery main switch |
1 |
$997.11 |
I003 |
|
-
|
99761318370
|
switch outer |
1 |
$326.78 |
I003 |
|
-
|
99761318770
|
switch inner |
1 |
$116.47 |
I003 |
|
-
|
99761192770
|
wiring harness adapter battery main switch(FROM YEAR 10 UP) |
1 |
$127.12 |
I003 |
